PRODUCTS
EPSON VIBRATION SENSORS
Three-axis digital vibration sensors that output velocity and displacement directly, for condition monitoring and predictive maintenance.
Condition data, ready to use
Instead of streaming raw acceleration, Epson vibration sensors calculate velocity and displacement inside the sensor and output them as raw values, RMS or peak-to-peak. This reduces processing load on your controller and the data volume in IIoT networks.
AMCORIS supplies Epson vibration sensors and supports you from selection and evaluation to integration into your monitoring system.
QUICK ANSWER
Vibration sensor or accelerometer?
Choose a vibration sensor when you want standard condition values such as velocity RMS directly from the sensor. Choose an accelerometer such as the M-A352AD10 when you need raw acceleration for your own FFT, very low frequencies or structural monitoring.
INSIDE THE SENSOR
From vibration to condition value
1
Sense
Three-axis acceleration at the machine.
2
Integrate
Velocity from 10 to 1000 Hz and displacement from 1 to 100 Hz.
3
Compute
Raw values, RMS or peak-to-peak, selectable.
4
Output
Digital data via UART/SPI or RS-422 to your controller or gateway.
Sources: Epson data sheets M-A342VD10 and M-A542VR10.
